D-Link DES-1016A 16-Port Fast Ethernet Unmanaged Switch — Fanless | D-Link Green | MTCTE Certified

The D-Link DES-1016A is built for small and medium businesses, SOHO environments, educational labs, retail stores, and expanding office networks who need a reliable 16-port Fast Ethernet switch to connect a large number of wired devices — desktop PCs, laptops, printers, IP cameras, VoIP phones, and network-attached storage — without complex configuration or ongoing management. It is well-suited for offices outgrowing 5- or 8-port switches, computer labs, small server rooms, and any environment requiring silent fanless operation alongside broad 16-device wired connectivity.

The DES-1016A delivers sixteen 10/100 Mbps Fast Ethernet ports with 3.2 Gbps total switching capacity and a maximum packet forwarding rate of 2.38 Mpps for reliable, wire-speed Fast Ethernet performance across all sixteen ports simultaneously. Auto MDI/MDIX on every port eliminates the need for crossover cables — any standard Ethernet cable connects any device without issue. The fully fanless design operates in complete silence, making it ideal for open-plan offices, classrooms, and any environment where fan noise is undesirable. D-Link Green Technology automatically saves energy through two key methods: automatic port power-down when no link is detected (such as when connected devices are powered off), and cable length-based power optimisation that uses only as much power as each cable length requires — both functioning without any user interaction or performance trade-off. WEEE compliance ensures the switch meets European and Indian environmental standards for reduced hazardous materials and recyclable packaging. 802.3x Flow Control prevents packet loss during high-traffic periods. A generous 2MB packet buffer handles burst traffic efficiently for smooth file transfers and media streaming across all sixteen connected devices simultaneously. Universal AC input (100–240V) ensures compatibility with Indian power infrastructure. MTCTE certification confirms compliance with Indian telecommunications regulatory requirements. LED indicators per port provide at-a-glance link and activity status for easy monitoring.

Model: DES-1016A
Switch Type: Unmanaged Desktop Switch
Interfaces: 16× 100Base-TX (RJ-45) — 10/100 Mbps | Auto MDI/MDIX
Switching Capacity: 3.2 Gbps
Max. Packet Forwarding Rate: 2.38 Mpps
Forwarding Method: Store-and-Forward
Packet Buffer Size: 2 MB
Flow Control: IEEE 802.3x
Power Saving — Link Status: Yes (auto port power-down when no link)
Power Saving — Cable Length: Yes (auto power reduction by cable length)
Cooling: Fanless (passive cooling)
Power Input: AC 100–240V (universal)
Max. Power Consumption: 2.69W
Dimensions: 155.7 × 122 × 41mm (W × D × H)
Weight: 0.27 kg
Operating Temperature: 0°C to 40°C
Storage Temperature: -40°C to 70°C
Operating Humidity: 10% to 90% RH
Storage Humidity: 5% to 90% RH
Certification: MTCTE Certified (India), RoHS, WEEE

System Requirements: Compatible with any device featuring a standard 10/100 Mbps Ethernet RJ-45 port; universal AC 100–240V power input — no separate adapter required; no configuration, drivers, or software required — plug-and-play out of the box; Auto MDI/MDIX on all ports allows use of any standard straight-through or crossover Ethernet cable

Setup: Connect power cable to AC outlet, connect devices via standard Ethernet cables to any of the 16 ports; switch auto-negotiates speed and duplex settings per connected device; no management interface or VLAN configuration available — unmanaged switch

Mounting Options: Compact desktop placement; rubber feet for stable surface use; suitable for desktop, shelf, or server room table placement

Usage Environment: Ideal for small and medium offices, SOHO environments, educational labs, retail stores, and growing wired networks requiring reliable silent 16-port Fast Ethernet switching with automatic energy-saving features
